2 person – Clam Shell
Regular price
$89,000.00
Unit price
per
Features
A spacious two-person hyperbaric chamber combining aerospace-grade aluminium construction with a refined, rounded shell design. Lightweight yet highly durable, the cabin offers excellent pressure resistance while placing less demand on floor loading — an important consideration for private homes, upper-floor installations and luxury recovery spaces.
The spacious interior features premium zero-gravity seating, while the sliding hatch provides easy access and the cabin can be separated into two sections for transport and installation. Integrated disinfection, oxygen generation and climate control create a comfortable, considered environment for every session.
Optional: BIBS safe breathing system and integrated red light therapy.
Chamber Specification
| Spec | Details |
|---|---|
| Chamber Type | Two-person hard-shell |
| Capacity | 2 people |
| Pressure | 2.0 ATA |
| Chamber Dimensions | 2000 × 1480 × 1700 mm |
| Chamber Net Weight | Approx. 380 kg |
| Package Dimensions | 2200 × 1600 × 1900 mm |
| Chamber Gross Weight | Approx. 490 kg |
| Construction | Aerospace-grade aluminium alloy |
| Cabin Design | Rounded shell |
| Seating | Premium zero-gravity sofa |
| Door System | High-precision horizontal sliding hatch |
| Safety System | Multi-pressure control safety system with automatic pressure stabilisation |
| Control System | Dual touchscreens inside & outside |
| Disinfection | IFD physical disinfection technology |
| Negative Oxygen Ions | Approx. 2,000,000 ions/cm³ |
| Main Unit | Integrated 3-in-1 design |
| Main Unit Functions | Air compressor + oxygen generator + air conditioner |
| Oxygen Generation | PSA |
| Assembly | Cabin separates into two sections for transport and installation |
| BIBS | Optional |
| Red Light Therapy | Optional |
Main Unit 3-in-1 Specification
| Spec | Details |
|---|---|
| Rated Power | 2-seat: 1000–2200 W |
| Control Mode | Fixed intelligent touchscreen |
| Oxygen Outlet Pressure | 100–140 kPa |
| Oxygen Generation Mode | PSA technology |
| Oxygen Production Flow | 15 L/min |
| Oxygen Concentration | 90% ±3% at concentrator outlet |
| Noise Level | ≤50 dB |
| Air Conditioning Mode | Water-cooled air conditioner |
| Temperature Control Range | 5–55 °C |
